LF                     3 Typ.
          SW/S                                  DCONWS
          Drive Shanks for SELF-GRIP
          Slitting Cutters           Screw  BD DBC             DCONMS  DBC       DCONMS  BD
                                                    LPR           DCONWS
                                                        LF
                                                    SW- Type            S- Type                   SW20


           Designation           DCONMS       BD          DBC       DCONWS       LPR         LF          kg
           SW 20                  20.00       20.00       14.40       8.00        -          100.00      0.24
           SW 25-23               25.00       23.00       13.60       6.00       25.0        110.00      0.00
           SW 25-28               25.00       28.00       18.00       8.00       25.0        110.00      0.43
           SW 25-32               25.00       32.00       22.00      10.00       25.0        110.00      0.51
           SW 32-40               32.00       40.00       32.00      22.00       30.0        120.00      0.60         SLOTTING & SLITTING CUTTERS
           S 32-55                32.00       55.00       45.00      32.00        -          60.00       0.84
           S 40-80                40.00       80.00       63.00      40.00        -          60.00       1.78
          For tools, see pages: GM-DG (374) • SGSA (372) • SGSF (370) • TGSF (364)

          Spare Parts
           Designation
           SW 20       SR M5X20 DIN7991  HW 3.0
           SW 25-23      SR 34-510  T-15/5
           SW 25-28      SR 76-961  T-15/5
           SW 25-32      SR 76-961  T-15/5
           SW 32-40      SR 76-963  T-15/5
           S 32-55       SR 76-943           BLD T20/M7  SW6-T
           S 40-80       SR 76-944     HW 6.0





                                                         DCONMS
          R (drive flange set)                                           LB     D4
          Drive Flange Set for
          Slitting Cutters                                   BD         DBC




           Designation             DCONMS            BD              DBC              D4               LB
           R 22-46                  22.00            46.00           32.00            5.00            10.00
           R 32-55                  32.00            55.00           45.00            6.00            10.00
           R 40-80                  40.00            80.00           63.00            11.00           12.00
           R 50-110                 50.00            110.00          80.00            14.00           14.00





                                                                          OAL      CW

          SGSF/A-M-JHP                                               THSZMS   LF
          Grooving and Slitting Small                                              CDX
          Diameter Cutters with FLEXFIT
          Threaded Adaptation                               DCONMS                    DC                    Bar Max
                                                                           DRVS


           Designation         DC    CW    CDX   CICT (1)  DCONMS THSZMS  LF  OAL  DRVS (2)  Insert  TQ_3 (3)
           SGSF 32-2-M08-3Z-JHP  32.00  2.00  7.80  3   13.00  M08    12.00  29.50  9.6  GSFN 2/GSFU 2.2  20  ESG 1.4-2*
           SGSA 32-3-M08-4Z-JHP  32.00  3.00  7.80  4   13.00  M08    12.87  30.37  9.6   GSAN 3...  20  ESG 1.4-2*
           SGSF 40-2-M10-4Z-JHP  40.00  2.00  11.80  4  18.00  M10    12.00  29.50  15.0  GSFN 2/GSFU 2.2  29  ESG 1.4-2*
           SGSA 40-3-M10-6Z-JHP  40.00  3.00  11.80  6  18.00  M10    12.10  32.10  15.0  GSAN 3...  29  ESG 1.4-2*
          •  For best performance use internal coolant with "CH" type shanks   •  When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and
          threaded areas must be thoroughly cleaned.  Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the
          TQ_3 parameter
          (1)  Number of inserts
          (2)  Torque key size
          (3)  Tool tightening torque Nxm (lbfxin)
          *  Optional, should be ordered separately
          For inserts, see pages: GSAN (372) • GSFN (373) • GSFU (373)
          For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
          •  HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312)
