P. 456

MILLING INSERTS  APKT 1003R8T-FF             Dimensions  INSL  W1 AE  APMX  S  Tough 1   Hard  Recommended    Rd°
                                                                 RE9.9
                                                             RE
          Insert for Fast Feed Milling






                                                                                                  Machining Data


                                                                                                 ap
                                                                                                           fz
                                                                                     IC830
                                                                                           IC808
                                                                            RE
                                                                   S
           Designation
                                                                             (2)
                                        INSL
                                                APMX
                               W1
                                                          AE
                                                                                                          (mm/t)
                                                                                                 (mm)
                                                                                    •
                                                                                          •
                                                                            1.90
                                                          4.5
                               6.60
                                        10.80
                                                                   3.50
           APKT 1003R8T-FF
                                                                                                         0.50-1.50
                                                                                                0.50-1.00
                                                 1.00
                                                                                          •
                               6.60
                                                          4.5
                                                 0.70
                         (1)
                                                                            1.90
                                                                                                0.50-1.00
                                                                                                         0.50-1.50
           APKT 1003R8GT-FF
                                        10.80
                                                                   3.50
          •  The actual diameter of the tool is 0.1 mm larger than the nominal diameter when using this insert   •  Tool corner should be modified by rounding to 2.0 mm.   •  Should be
          used on tools of 12 mm diameter and up   •  At D.O.C. larger than ap max, regular insert feed should be applied   •  For cutting speed recommendations, see pages 542-547
          (1)  Reinforced cutting-edge geometry for Fast Feed (FF) hardened materials up to 64 HRc
          (2)  Radius for CNC programming is considered as 1.8 mm
          For tools, see pages: HM90 E90A-10 (24) • HM90 E90A-M-10 (28) • HM90 E90A-MM-10 (27) • HM90 E90A-MM-10-JHP (27) • HM90 F90AP-10 (200)
          •  HM90 F90AP-10-JHP (200)
                                   Tool with a
          Standard Tool            Modified Corner
                                                                           Tool corner
                                                                           should
                                                                          3° bemodified
                                                                           by rounding
                                                                           to 2 mm
                                                                   DC+0.1

                                                                   W1
          HM90 ADKT 1505
          Inserts with 2 Helical Cutting                                                                Rd°
          Edges for General Use                                        APMX  INSL
                                                                 BS    RE        S
                                                                                                  Recommended
                                          Dimensions                   Tough 1   Hard
                                                                                                  Machining Data
                                                             IC882  IC330  IC328  IC830  IC928  IC5400  IC950  IC380  IC808  IC908  IC810  IC910  ap  fz
           Designation          W1   INSL  APMX  S  RE  BS                                       (mm)    (mm/t)
           HM90 ADKT 1505PDR    9.65  16.18  12.00  5.85  0.80  2.16 • • • • • • • • • • • •   1.20-12.00  0.08-0.15
           HM90 ADKT 1505PDR-MM  9.60  16.00  12.00  5.80  0.80  2.70  •                       1.20-12.00  0.08-0.15
           HM90 ADKT 150516-PDR  9.65  15.60  12.00  5.92  1.60  1.37                 •        2.00-12.00  0.08-0.15
           HM90 ADKT 150520-PDR  9.65  15.60  12.00  5.90  2.00  0.79                 •        2.40-12.00  0.08-0.15
           HM90 ADKT 150524-PDR  9.65  15.60  12.00  5.80  2.40  0.52                 •        2.80-12.00  0.08-0.15
           HM90 ADKT 150532-PDR  9.65  15.20  12.00  5.85  3.20  -                    •        3.60-12.00  0.08-0.15
           HM90 ADKT 150540-PDR  9.65  14.83  12.00  5.80  4.00  -                    •        4.40-12.00  0.08-0.15
           HM90 ADKT 150550-PDR  9.65  14.85  12.00  5.75  5.00  -                    •        5.40-12.00  0.08-0.15
           HM90 ADKT 150564-PDR  9.65  14.85  12.00  5.65  6.40  -                    •        6.80-12.00  0.08-0.15
          •  For inserts with corner radii larger than 2.0 mm, the cutter body and seats should be modified   •  Inserts with corner radii larger than 0.8 mm should be used on ADK & SM
          tools only on the face of the cutter.   •  For cutting speed recommendations, see pages 542-547
          For tools, see pages: F90AD-SFR (211) • HM90 E90AD-15 (31) • HM90 E90AD-M-15 (32) • HM90 E90AD-M-15-JHP (32) • HM90 F90A-15 (210)
          •  HM90 F90A-15-JHP (210) • SM (250)
          HM90 ADKT 1505PDR-MM     •  Cutting edge geometry with low axial angle
                                   •  Reinforced cutting edge geometry, which provides better chipping resistance
                                   •  Wide frontal wiper that leaves excellent surface finish on the workpiece
                                   •  Used for unfavorable conditions and high feeds
