P. 464

MILLING INSERTS      HM90 ADKW 1505PDR        Dimensions  BS 1 2  APMX  lNSL  S  Tough 1   Hard  Machining Data
                                                               W1
          Milling Inserts for Unfavorable
                                                                                                        Rd°
          Conditions and Heavy Interrupted
          Cut on Hardened Steel
                                                                    RE
                                                                                                  Recommended




                                                                                                 ap
                                                                                                           fz
                                                 APMX
           Designation
                                 W1
                                                                   RE
                                         INSL
                                                                            BS
                                                                                                         (mm/t)
                                                           S
                                                                                                 (mm)
                                                  12.00
                                 9.59
           HM90 ADKW 1505PDR
                                         16.15
          •  Reinforced cutting edge, resistant to edge breakage and chipping   •  Recommended for milling at unfavorable conditions and heavy interrupted cut   •  Different corner radii
          can be ground   •  For cutting speed recommendations, see pages 542-547  5.83  0.80  2.45  • IC928  • IC908  • IC910  1.20-12.00  0.08-0.15
          For tools, see pages: F90AD-SFR (211) • HM90 E90AD-15 (31) • HM90 E90AD-M-15 (32) • HM90 E90AD-M-15-JHP (32) • HM90 F90A-15 (210)
          •  HM90 F90A-15-JHP (210) • SM (250)
                            Conventional                                             MILL2000
                                                                          Helical cutting edge for a smooth cut
          Dovetail side shape gives better support,                       Thick insert for improved strength and rigidity
          eliminates possible pullout from seat
                                                                          Positive rake angle for low cutting forces
          Ground wiper controls surface finish at high feeds













                                                                W1

          3M AXKT 1304
          High Durability Inserts
          for Heavy Milling                                          APMX INSL


                                                               BS    RE        S
                                              Dimensions                      Tough 1   Hard         Recommended
                                                                                                     Machining Data



                                                                       IC330  IC328  IC830  IC928  IC950  IC808  IC908  IC810  IC910  ap  fz
           Designation           W1    INSL  APMX   S     RE    BS                                   (mm)  (mm/t)
           3M AXKT 1304PDR       8.40  14.12  12.00  4.55  0.60  2.10  •  •  •     •  •   •  •     1.00-12.00 0.15-0.35
           3M AXKT 1304PDR-MM    8.40  14.12  12.00  4.55  0.60  2.10    •      •  •      •      •  1.00-12.00 0.10-0.22
          •  For cutting speed recommendations, see pages 542-547

          PDR-MM       PDR
