MILLING INSERTS H400 RNHU Dimensions L W1 RE APMX S Recommended Machining Data
Rd°
Double-Sided Inserts with Four

5, 6 and 8 mm Radii Cutting
Edges for Profile Milling

Tough 1 Hard

ap
fz
(mm/t)
(mm)
RE
L
Designation
S
H400 RNHU 1004-AX
7.50
9.30
•
(2)
H400 RNHU 1004-HP
1.00-5.00
5.00
9.30
9.20
0.10-0.30
7.50
4.05
•
•
1.00-5.00
5.00
7.50
(3)
9.20
H400 RNHU 1004-ML (1) 5.00 9.20 W1 APMX 4.70 IC330 • IC830 • IC808 1.00-5.00 0.10-0.30
4.05
0.10-0.30
9.30
H400 RNHU 1205-AX (1) 6.00 11.00 11.20 8.70 5.20 • • 2.00-6.00 0.15-0.30
H400 RNHU 1205-HP (2) 6.00 11.00 11.20 8.70 4.75 • • 2.00-6.00 0.15-0.30
H400 RNHU 1205-ML (3) 6.00 11.00 11.20 8.70 4.75 • • 2.00-6.00 0.15-0.30
H400 RNHU 1606-AX (1) 8.00 14.70 13.90 12.00 7.80 • • • 3.00-8.00 0.15-0.40
H400 RNHU 1606-HP (2) 8.00 14.70 13.90 12.00 7.80 • 3.00-8.00 0.15-0.40
H400 RNHU 1606-ML (3) 8.00 14.70 13.90 12.00 7.80 • • 3.00-8.00 0.15-0.40
• For cutting speed recommendations, see pages 542-547
(1) First priority for austenitic stainless steel, second priority for steel, ferritic and martensitic stainless
(2) First priority for titanium and high temperature alloys, second priority for austenitic stainless steel
(3) First priority for steel, ferritic and martensitic stainless steel, second priority for austenitic stainless steel
For tools, see pages: H400 ER-10 (282) • H400 ER-12 (282) • H400 ER-M (283) • H400 FR-10 (283) • H400 FR-12 (284) • H400 FR-16 (285)
ML HP AX

Rd°
H606 RXCU 1206 IC
Double-Sided Inserts with
Six 6 mm Radius Cutting
Edges for Profile Milling
RE
S
Dimensions Tough 1 Hard Recommended Machining Data
IC330 IC830 IC808 ap fz
Designation IC RE S (mm) (mm/t)
H606 RXCU 1206-AXMP (1) 12.20 6.00 5.90 • • • 2.00-6.00 0.10-0.40
H606 RXCU 1206-AXT (2) 12.20 6.00 5.90 • • 2.00-6.00 0.10-0.40
• For cutting speed recommendations, see pages 542-547
(1) For stainless steel and high temperature alloys
(2) For steel and cast iron applications
For tools, see pages: H606 ER-M (285) • H606 FR-12 (286)
AXMP AXT
